Product Image Images for illustration purposes only
Product Image
Clamp Assemblies Standard Series Size 1a Ø9,5mm Polypropylene W10 Slotted Head Screw Weld Plate, short

SP-109a-PP-LI-M-W10

Stauff Mat. No. 1110007877
View Technical details
List price
This material is only available on request. Add to request list

If you have a regular demand for pipework equipment or hydraulic components and you are interested in individual pricing for our product range, please contact STAUFF.

STAUFF Online Page-Flip Catalog
Navigate and search content, forward via email, print, and download in PDF format
Open STAUFF Online Page-Flip Catalog in New Tab

STAUFF product catalogue

Download catalog
Standard
DIN 3015-1
STAUFF Series
Standard Series
STAUFF Size
Group 1A (DIN 3015 Size 1)
Type of Installation
Single Weld Plate
Mounting & Fitting Combination
Slotted Head Screw
Installation of Pipes
yes
Installation of Hoses
no
Installation of Cables
no
fixed installation of line
yes
sliding installation of line
no
Vibration Reducing
low
Tension Clearance
yes
Inside Surface
Profiled
for Diameter (mm)
09
Material (Clamp Body)
PP Polypropylene
Material (Weld Plate)
Steel, Phosphated
Material (Bolt)
Steel, Zinc-Nickel coated
Gross Weight
0.057 kg
Packaging unit
1 piece
The product shown above is a kit consisting of several individual components. It is not always possible to order all individual components of a kit separately in the STAUFF online shop. Below you will find an overview of all purchasable individual components of the kit. Please note: If you order these components individually, please make sure to check that the kit is complete to ensure that it functions properly.
Product Image
SP-1A-M-W2
Weld Plate Standard Series Size 1a Carbon Steel, Phosphated DIN 3015
Material No.
1120001153
Required Quantity
1 piece
Product Image
LI-M6x20-ISO1207-4.8-W3
Slotted Head Screw M6x20 Standard Series Size 1/1a Carbon Steel, Zinc/Nickel Coat Please order the suitable Washer in addition: 1130002821 (US W3)
Material No.
1130003951
Required Quantity
2 pieces
